ALVÖRA Speciality Lubricants Hydraulic AW (ISO VG 32, 46, 68, 100)

Executive Summary

ALVÖRA Hydraulic AW is a high-performance anti-wear hydraulic oil series engineered with German technology to provide exceptional protection, thermal stability, and operational efficiency for industrial and mobile hydraulic systems. Available in ISO VG grades 32, 46, 68, and 100, ALVÖRA Hydraulic AW ensures reliable power transmission, reduced wear, and extended equipment service life across demanding operating environments.

Key Features & Benefits

  • Anti-Wear Performance: Advanced anti-wear additive technology protects hydraulic pumps, valves, and cylinders against premature scuffing and mechanical wear.
  • Thermal & Oxidation Stability: Resists oil breakdown, varnish accumulation, and sludge formation under high operating temperatures and pressures.
  • Corrosion & Rust Protection: Shields ferrous and non-ferrous internal metal components from rust and oxidation even in moisture-rich environments.
  • Rapid Water Separation & Foam Control: Excellent demulsibility ensures fast separation from water, while anti-foam properties maintain steady hydraulic pressure and prevent pump cavitation.
  • Consistent Viscosity Profile: Formulated to maintain reliable film strength and flow characteristics across varied operating temperatures.

Product Applications

ALVÖRA Hydraulic AW is recommended for:

  • Industrial hydraulic systems operating under moderate to high pressures and temperatures.
  • Mobile hydraulic equipment, including construction machinery, agricultural equipment, and material handling systems.
  • Circulating systems, vane, gear, and heavy-duty axial piston pumps requiring anti-wear hydraulic fluids across a wide viscosity range.

Product Data Sheet (PDS)

Technical Specifications & Typical Properties

Property Test Method Unit ISO VG 32 ISO VG 46 ISO VG 68 ISO VG 100
ISO Viscosity Grade — — 32 46 68 100
Kinematic Viscosity @ 40°C ASTM D445 cSt 32.8 45.8 67.8 100.0
Kinematic Viscosity @ 100°C ASTM D445 cSt 5.5 6.8 8.7 11.2
Viscosity Index ASTM D2270 — 100 100 100 98
Density @ 15°C / 60°F ASTM D4052 $\text{g/cm}^3$ 0.88 0.88 0.88 0.89
Flash Point (min) ASTM D92 °C 220 220 220 230
Pour Point (max) ASTM D97 °C -18 -18 -18 -15

Packing Size:  20L,208L & 1000L

Performance Standards & Recommendations

  • Engineered in Germany for industry worldwide.
  • Designed to meet rigorous anti-wear and hydraulic fluid standards.

Storage & Handling

  • Storage: Store all packages under cover. If outside storage is unavoidable, drums should be laid horizontally to prevent water ingress and damage to drum markings. Never store products above 60°C, exposed to hot sun, or in freezing conditions.
  • Health & Safety: When used as directed with proper personal hygiene, ALVÖRA Hydraulic Oil does not pose significant health or safety risks. Avoid skin contact and wear gloves when handling used oil. Wash immediately with soap and water in case of skin exposure.
  • Environmental Protection: Dispose of used oil at an authorized collection facility. Do not release used lubricants into drains, soil, or water sources.

ALVÖRA Speciality Lubricants Lithium Grease Series

Product Overview

The ALVÖRA Lithium Grease Series comprises high-performance, multi-purpose lubricating greases formulated with refined mineral base oils and thickened with high-grade lithium soap structures. Engineered to deliver exceptional mechanical stability, oxidation resistance, and robust load-carrying capabilities, this comprehensive series covers a wide range of National Lubricating Grease Institute (NLGI) consistency grades—from fluid greases designed for centralized lubrication systems to heavy consistency grades suitable for extreme-load industrial bearings.

Comprehensive Series Performance Grades

NLGI Grade Penetration (ASTM D217) Typical Consistency Primary Application Scope
NLGI 000 445 – 475 Semi-fluid / Pourable Enclosed gearboxes, centralized truck lubrication systems, and heavy-duty gear housings requiring flowable grease.
NLGI 00 400 – 430 Fluid / Semi-fluid Centralized lubrication systems in industrial plants, mobile machinery, and truck chassis lubrication.
NLGI 0 355 – 385 Very Soft Industrial gearboxes, heavy-duty centralized systems, and low-temperature bearing applications.
NLGI 1 310 – 340 Soft Plain and anti-friction bearings operating under continuous vibration or extended lubrication intervals.
NLGI 2 265 – 295 Normal (Standard) Automotive chassis points, wheel bearings, universal joints, electric motors, and general industrial machinery.
NLGI 3 220 – 250 Firm / Hard High-speed wheel bearings, vertical shaft bearings, and applications requiring high resistance to centrifugal throw-off.

Key Features & Benefits

  • Comprehensive Consistency Range: Formulated across multiple NLGI grades to match specific pumpability, flow, and structural load requirements.

  • Mechanical Stability: Resists structural breakdown and softening under severe shear stress, high vibration, and continuous mechanical working.

  • Effective Corrosion Protection: Shields metal surfaces against rust, saline environments, and acidic moisture oxidation.

  • Water Washout Resistance: Maintains grease film integrity and adhesion even under direct exposure to water and wet operating conditions.

  • High Load-Carrying Capacity: Incorporates anti-wear and optional extreme-pressure (EP) additives to protect heavily loaded sliding and rolling elements from shock loads.

General Technical Specifications (Lithium Grease Series)

Technical Parameter Test Method Typical Range / Value Unit
Thickener Type — Lithium Soap (12-Hydroxystearate) —
Base Oil Type — High-Viscosity Solvent-Refined Mineral Oil —
Dropping Point ASTM D566 180 min (Standard) / 190 min (EP grades) °C
Base Oil Viscosity @ 40°C ASTM D445 100 – 220 cSt
Four-Ball Weld Load (EP Grades) ASTM D2596 250 min kgf
Water Washout @ 79°C ASTM D1264 < 5.0 % wt
Operating Temperature Range — -20°C to +130°C (Intermittent up to +140°C) °C

(Note: Typical values are numerical guidelines spanning the series and do not constitute an exact sales specification for individual grades.)

Recommended Applications

  • Automotive & Commercial Transport: Wheel bearings, chassis joints, kingpins, steering linkages, spring shackles, and universal joints.

  • Industrial Manufacturing: Conveyor rollers, electric motor bearings, crusher bearings, compressor components, and general workshop lubrication points.

  • Agricultural & Heavy Equipment: Tractors, earthmoving machinery, harvesters, and implement pivot pins operating in demanding outdoor environments.

ALVÖRA Speciality Lubricants Extreme Pressure (EP) Lithium Grease Series

Product Overview

The ALVÖRA EP Lithium Grease Series (featuring EP 0, EP 2, and EP 3) is formulated with high-viscosity mineral base oils, thickened with high-grade lithium soap, and fortified with advanced Extreme Pressure (EP), anti-wear, rust-inhibiting, and oxidation-stability additives. Engineered to handle high shock loads, heavy industrial stress, and boundary lubrication conditions, this series ensures long-term component protection across diverse operational environments.

Grade Comparison & Technical Specifications (EP 0, EP 2, EP 3)

Technical Parameter Test Method EP 0 (Soft / Centralized) EP 2 (Standard Multi-Purpose) EP 3 (Firm / High-Speed)
NLGI Grade ASTM D217 0 2 3
Worked Penetration @ 25°C ASTM D217 355 – 385 265 – 295 220 – 250
Texture / Appearance Visual Smooth / Semi-Fluid Smooth / Buttery Smooth / Firm
Thickener Type — Lithium Soap Lithium Soap Lithium Soap
Dropping Point ASTM D566 180 min 190 min 190 min
Four-Ball Weld Load ASTM D2596 250 kgf min 250 kgf min 250 kgf min
Base Oil Viscosity @ 40°C ASTM D445 150 cSt 150 cSt 150 cSt
Water Washout @ 79°C ASTM D1264 < 5.0% wt < 5.0% wt < 5.0% wt
Operating Temperature Range — -20°C to +120°C -20°C to +130°C -20°C to +130°C

(Note: Typical values are numerical guidelines spanning the series and do not constitute an exact sales specification.)

Detailed Grade Breakdown

1. ALVÖRA EP 0 (Soft / Centralized Systems)

  • Characteristics: A soft, semi-fluid grease designed for superior pumpability.

  • Primary Applications: Centralized lubrication systems in industrial plants, enclosed industrial gearboxes, and truck chassis lubrication systems requiring a flowable grease.

2. ALVÖRA EP 2 (Standard Multi-Purpose EP)

  • Characteristics: The industry-standard multi-purpose grease offering an optimal balance of structural stability, load-carrying capacity, and pumpability.

  • Primary Applications: Heavy-duty automotive wheel bearings, universal joints, chassis suspension points, construction equipment pivot pins, and general industrial plain/anti-friction bearings.

3. ALVÖRA EP 3 (Firm / High-Load Bearings)

  • Characteristics: A firmer consistency grease engineered to resist centrifugal throw-off and maintain film thickness under high rotational speeds and heavy continuous loads.

  • Primary Applications: High-speed electric motor bearings, vertical shaft bearings, agricultural machinery, and industrial equipment operating under high vibration and heavy shock loads.

Key Features & Benefits

  • Extreme Pressure (EP) Performance: Fortified with EP additives to prevent scoring and scuffing of metal surfaces under high shock loads.

  • Outstanding Mechanical Stability: Resists softening or structural breakdown under severe continuous mechanical working and heavy shear forces.

  • Corrosion & Oxidation Resistance: Effectively protects metal components against rust, saline moisture, and chemical degradation.

  • Superior Water Resistance: Retains adhesion and structural integrity even under direct exposure to water washout in wet operating environments.

Packaging Availability

  • Packs: 400g Cartridges (EP 2 & EP 3), 15kg Pails, 50kg Kegs, and 180kg Steel Drums.
